Omron Q2A Series Technical Manual

Parameter List
11
11.20 Parameters Changed by PM Motor Code Selection
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 503
No. Name Unit Motor Code (setting value of E5-01)
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 113.84 77.84 40.00 27.52 31.73 23.09 25.28 13.36
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 157.16 103.56 60.80 37.00 40.88 34.39 35.20 18.44
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 490.8 513.8 543.7 520.3 580.8 602.7 601.5 584.6
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-09 Min Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6
C5-17 Motor Inertia kgm
2
0.0016 0.0022 0.0081 0.0133 0.0133 0.017 0.027 0.044
L3-24
*1
Acc@Rated Torque s 0.092 0.068 0.125 0.139 0.083 0.070 0.082 0.092
n5-02
Mot Inertia
Acceleration Time
s 0.092 0.068 0.125 0.139 0.083 0.070 0.082 0.092
n8-49 Heavy Load Id Current % -9.5 -9.4 -13.7 -10.0 -12.9 -19.9 -22.8 -19.8
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.17 SST4 Series Motor Code Setting for Specification of 400 V at 1450 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 233E 233F 2340 2342 2343 2344 2345 2346
Voltage Class V 400 400 400 400 400 400 400 400
Capacity kW 15 18 22 30 37 45 55 75
Motor Rotation Speed min
-1
1450 1450 1450 1450 1450 1450 1450 1450
E5-02
PM Mot Rated Power
(kW)
kW 15 18.50 22.00 30.00 37.00 45.00 55.00 75.00
E5-03
PM Mot Rated Current
(FLA)
A 27.1 34.2 37.6 50.9 65.4 80.2 96.1 129.2
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 0.291 0.220 0.192 0.136 0.091 0.064 0.048 0.028
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 11.77 8.94 8.32 6.68 5.30 3.76 3.09 2.24
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 14.60 11.40 10.64 8.16 6.80 4.88 4.75 3.03
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 610.3 595.2 711.6 710.8 652.7 604.8 669.1 646.8
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-09 Min Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6
C5-17 Motor Inertia kgm
2
0.054 0.063 0.113 0.137 0.252 0.304 0.41 0.55
L3-24
*1
Acc@Rated Torque s 0.083 0.079 0.118 0.105 0.157 0.156 0.172 0.169
n5-02
Mot Inertia
Acceleration Time
s 0.083 0.079 0.118 0.105 0.157 0.156 0.172 0.169
n8-49 Heavy Load Id Current % -14.5 -16.1 -11.8 -10.5 -15.6 -17.4 -21.7 -17.3
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
