11.20 Parameters Changed by PM Motor Code Selection
504 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Table 11.18 SST4 Series Motor Code Setting for Specification of 400 V at 1450 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 2347 2348 2349 234A 234C 234D
Voltage Class V 400 400 400 400 400 400
Capacity kW 90 110 132 160 200 250
Motor Rotation Speed min
-1
1450 1450 1450 1450 1450 1450
E5-02
PM Mot Rated Power
(kW)
kW 90.00 110.00 132.00 160.00 200.00 250.00
E5-03
PM Mot Rated Current
(FLA)
A 153.1 191.7 226.0 268.8 331.3 422.9
E5-04 PM Mot Pole Count - 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 0.024 0.015 0.011 0.007 0.006 0.003
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 2.20 1.34 1.23 0.92 0.84 0.61
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 3.23 2.16 1.67 1.30 1.25 0.89
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 708.0 637.8 677.0 661.7 687.1 655.9
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0 0.0
E1-04 Max Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5
E1-09 Min Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6
C5-17 Motor Inertia kgm
2
0.82 0.96 1.60 1.95 2.82 3.70
L3-24
*1
Acc@Rated Torque s 0.210 0.201 0.279 0.281 0.325 0.341
n5-02
Mot Inertia
Acceleration Time
s 0.210 0.201 0.279 0.281 0.325 0.341
n8-49 Heavy Load Id Current % -19.6 -24.1 -15.1 -17.0 -19.8 -19.3
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.19 SST4 Series Motor Code Setting for Specification of 400 V at 1150 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 2432 2433 2435 2436 2438 243A 243B
Voltage Class V 400 400 400 400 400 400 400
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5
Motor Rotation Speed min
-1
1150 1150 1150 1150 1150 1150 1150
E5-02
PM Mot Rated Power
(kW)
kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5
E5-03
PM Mot Rated Current
(FLA)
A 0.89 1.72 3.02 4.58 7.40 10.21 13.75
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 10.720 6.080 4.336 2.143 1.428 1.199 0.648
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 122.20 61.16 70.24 46.20 33.87 41.67 21.24
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 170.80 97.12 90.04 60.28 42.98 69.15 33.04
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 626.1 626.1 703.1 727.6 699.0 861.5 759.7
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-09 Min Output Frequency Hz 2.9 2.9 2.9 2.9 2.9 2.9 2.9
