Parameter Details
12
12.10 o: KEYPAD
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 819
Item Specification
Line break code <CR><LF>
Separating character Commas
Header rows First row: Drive information including Drive Model, software version, control method, and sampling time
Second row: Log data information including the monitor number, number decimal points, and unit code
■ Log File Configuration
The [Log_Files] folder is created in the root directory of the micro SD card. This is where the log data is stored as
CSV files. Log data files are created in this configuration. The number of rows changes when the number of
selected monitors change.
First row Drive information
Second row Log data information
Third row Log data 1
: Log data 2
: Log data 3
: :
Last row Log data n
First Row: Drive Information
This example shows the data text strings and data generated for the first row of log data.
Example of generated data: 00,0012,160107111230,Q2A,VSAA01010,2,62,1000,000001
No. Item
Number
of
Charac
ters
Example Description
1 Attribute 2 00 [00] shows that the record is a drive information record.
2 File number 4 0012 The [xxx] part of the [Q0xxx.csv] filename is a 3-digit decimal number in hexadecimal format.
Example filename of [Q0018.csv]: 018 (Dec.) = 0012 (Hex.)
3 Time stamp
*1
12 160107111230 Date file was generated
・Date: 20YY/MM/DD
・Time in 24-hour format: HH:MM:SS
Example data of [160107111230]: 11:12:30 on January 7, 2016
4 Model 3 Q2A Drive model information
5 Software number 9 VSAA01010 Drive software number
6 Control method 1 2 Setting value (Hex.) of A1-02 [Control Method]
7 Drive capacity 2 62 Setting value (Hex.) of o2-04 [Drive KVA Selection]
8 Sampling time 5
(maximum)
1000 Setting value (Dec.) of o5-02 [Log Sample Lapse]
Unit: ms
9 Row number 6 000001 Row number (Hex.) in the data log file
*1 If you do not set the time in the keypad, the text string of [000000000000] is generated to show the time.
Second Row: Log Data Information
This example shows the data text strings and data generated for the second row of log data.
Example of generated data:
01,0012,160107111230,0101,0201,0102,0201,0103,0206,0107,0005,0108,0209,0000,0000,0000,0000,0000,0
000,0000,0000,0000,0000,0000,0000,0000,0000,000002
No. Item
Number of
Characters
Description
1 Attribute 2 [01] shows that the record is a log data information record.
2 File number 4 The [xxx] part of the [Q0xxx.csv] filename is a 3-digit decimal number in hexadecimal format.
3 Time stamp 12 Date file was generated
4 Monitor number 1
*1
4 Monitor number selected by o5-03 [Log Mon Data 1]
Ex.: 0101 (Dec.) for U1-01
To Next Page
