Omron R88D-1SAN-ECT Series - Page 72

72
3.
Double-click Section0 to display the section.
4.
Right-click CmdSrvOn and select Set/Reset − Set.
Check that the 7-segment LED display shows ‘oE.’.
5.
Right-click CmdVelStart and select Set/Reset − Set.
Check that the Servomotor rotates at about 600 r/min.
6.
Operate the Safety key Selector Switch to switch to maintenance mode.
Check that the Servomotor decelerates to a stop.
Check that the 7-segment LED display shows ‘SF’.
