Omron R88D-1SAN-ECT Series -  Setting the Network Configuration

33
◼ Setting the Network Configuration
1.
Double-click CPU Rack.
2.
Drag a system unit device to the location where you want to add it in the CPU and
Expansion Racks Tab Page.
In this example, drag the NX-PF0630 Additional I/O Power Supply Unit.
3.
Drag a safety CPU device to the location where you want to add it in the CPU and
Expansion Racks Tab Page.
In this example, drag the NX-SL3300 Safety CPU Unit.
