Test Run and Data Trace
1.
Right-click the Servo Drive and select Test Run from the menu.
2.
Click the Step Tab.
Adjust the motion profile.
Click the Apply Button.
3.
Click the Servo ON Button to turn ON the Servo.
4.
Right-click Data Trace Settings and select Add - Data Trace from the menu to add
a new data trace.
