11 Adjustment Functions
11-4
G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
Select the direction for analog monitor output voltage.
These are the output voltage range and the output direction when the Analog Monitor 1 Selection or
Analog Monitor 2 Selection is set to the feedback motor speed, and the Analog Monitor 1 Scale Setting
or the Analog Monitor 2 Scale Setting is set to 0 (i.e., 1V = 500 r/min).
Analog Monitor Output Setting (3421 Hex)
Set value Output range Data output
0 −10 to 10 V
1 0 to 10 V
2 0 to 10 V
(5 V as the center)
10 V
−
1
0
V
0 V
−
5000
5000 [r/min]
Feedback
Motor Speed
O
utput voltage [V]
10 V
−
10 V
0 V
−
5000
5000 [r/min]
O
utput voltage [V]
Feedback
Motor Speed
10 V
5 V
−
1
0
V
0 V 0
−
2500
2500 [r/min]
O
utput voltage [V]
Feedback
Motor Speed
