96
Frame Structure Section 6-2
Alarm Cause
■ Variable Type 80
Note The run time and temperature are represented by variables 0002 and 0003,
respectively.
Note If the upper limit of the displayable range is exceeded, the upper limit will be
displayed. If the lower limit is exceeded, the lower limit will be displayed.
Address Name Data range
1000 Voltage when abnormal voltage trip-
ping occurred
00A3 to 012C (16.3 to 30.0 V)
If the lower limit is exceeded:
0000
If the upper limit is exceeded:
7FFF
1002 Minimum voltage after undervoltage
is detected
Address Name Data range
1020 Current when abnormal current trip-
ping occurred in branch output 1
0000 to 00C8 (0.0 to 20.0 A)
If the lower limit is exceeded:
0000
If the upper limit is exceeded:
7FFF
1021 Current when abnormal current trip-
ping occurred in branch output 2
1022 Current when abnormal current trip-
ping occurred in branch output 3
1023 Current when abnormal current trip-
ping occurred in branch output 4
1024 Current when abnormal current trip-
ping occurred in branch output 5
1025 Current when abnormal current trip-
ping occurred in branch output 6
1026 Current when abnormal current trip-
ping occurred in branch output 7
1027 Current when abnormal current trip-
ping occurred in branch output 8
To Next Page
