97
Frame Structure Section 6-2
Parameters
Variable Type 81
Address Name Data range
0000 Undervoltage detection threshold (V) 00B4 to 0108 (18.0 to 26.4 V)
0002 Over-temperature output threshold (°C) 0019 to 005A (25 to 90°C)
0004 Protection level 0000 to 0002
(0: R/W allowed; 1: Limited R/
W; 2: Limited read-only)
0005 Remaining life threshold 0000 to 0032 (0.0 to 5.0
years)
0006 Alarm reset setting 0000 to 0001 (0: Key, 1: Key +
Power ON)
0007 External tripping input function setting 0000 to 0001 (0: Edge, 1:
Level)
Address Name Data range
0010 Current tripping type for branch output 1 0000 or 0002
(0: Standard; 1: Instanta-
neous, 2: Extended)
0011 Current tripping type for branch output 2
0012 Current tripping type for branch output 3
0013 Current tripping type for branch output 4
0014 Current tripping type for branch output 5
0015 Current tripping type for branch output 6
0016 Current tripping type for branch output 7
0017 Current tripping type for branch output 8
Address Name Data range
0020 Current tripping threshold for branch out-
put 1
0005 to 0026 (0.5 to 3.8 A)
0021 Current tripping threshold for branch out-
put 2
0022 Current tripping threshold for branch out-
put 3
0023 Current tripping threshold for branch out-
put 4
0024 Current tripping threshold for branch out-
put 5
0025 Current tripping threshold for branch out-
put 6
0026 Current tripping threshold for branch out-
put 7
0027 Current tripping threshold for branch out-
put 8
Address Name Data range
0050 Startup sequence for branch output 1 0000 to 03E7
(0: Disabled, or 0.1 to 99.9 s)
0051 Startup sequence for branch output 2
0052 Startup sequence for branch output 3
0053 Startup sequence for branch output 4
0054 Startup sequence for branch output 5
0055 Startup sequence for branch output 6
0056 Startup sequence for branch output 7
0057 Startup sequence for branch output 8
