98
Frame Structure Section 6-2
Number of Elements The number of elements is expressed in 2-byte hexadecimal. For the S8AS,
the setting range for the number of elements is 0 to 56 (decimal format) so
that all of the monitored values can be accessed together.
List of Services
Note No commands (services) will be accepted and no responses will be returned
when a memory error (RAM error) has occurred.
Address Name Data range
0060 Shutdown sequence for branch output 1 0000 to 03E7
(0: Disabled, or 0.1 to 99.9 s)
0061 Shutdown sequence for branch output 2
0062 Shutdown sequence for branch output 3
0063 Shutdown sequence for branch output 4
0064 Shutdown sequence for branch output 5
0065 Shutdown sequence for branch output 6
0066 Shutdown sequence for branch output 7
0067 Shutdown sequence for branch output 8
Address Name Data range
0070 External tripping input cutoff for branch
output 1
0000 or 0001
(0: Enabled; 1: Disabled)
0071 External tripping input cutoff for branch
output 2
0072 External tripping input cutoff for branch
output 3
0073 External tripping input cutoff for branch
output 4
0074 External tripping input cutoff for branch
output 5
0075 External tripping input cutoff for branch
output 6
0076 External tripping input cutoff for branch
output 7
0077 External tripping input cutoff for branch
output 8
MRC SRC Name of service Processing
01 01 Read Variable Area This service reads from variable areas.
01 02 Write Variable Area This service writes to variable areas.
05 03 Read Controller Attributes This service reads the model number and
communications buffer size.
06 01 Read Controller Status This service reads the operating status.
08 01 Echoback Test This service performs an echoback test.
30 05 Operation Command This service performs operations such as
reset.
