44
Installation
Section 3-2
3-2
Installation
When mounting the S8AS in
a panel, use DIN
Rail. Surf
ace installation cannot
be used.
Mounting in a P
anel
•
The S8AS must be installed in the orientation sho
wn below to ensure
adequate cooling.
•
Do not install the S8AS in an
y of the follo
wing orientations
.
Incorrect
Incorrect
Incorrect
Incorrect
61
63
