107
Operation Command Section 6-8
6-8 Operation Command
This service performs operation command processing.
■ Service Request PDU
■ Service Response PDU
(1) Command Codes and Related Information
Note (1) If a process is executed for all of the branch outputs and cannot be per-
formed on one or more of them, it will still be performed on the other out-
puts. In this case, a normal response will be returned, so check the
controller status display to confirm whether or not the outputs were actu-
ally connected or disconnected.
(2) After parameter initialization has been successfully completed, a normal
response will be returned and then a software reset will be performed.
(3) The response to parameter initialization will be returned immediately
even if a send wait time is specified.
MRC SRC
3 0 0 5
2 2 2 2
Command
Code
Related
Info.
MRC SRC
3 0 0 5
2 2 4
Response Code
Command
code
Command content Related Information
00 Immediately connect Each bit corresponds to a branch output.
(Multiple branch outputs can be specified.)
01: Branch output 1
02: Branch output 2
04: Branch output 3
08: Branch output 4
10: Branch output 5
20: Branch output 6
40: Branch output 7
80: Branch output 8
01 Immediately discon-
nect (Cut off)
Each bit corresponds to a branch output.
(Multiple branch outputs can be specified.)
01: Branch output 1
02: Branch output 2
04: Branch output 3
08: Branch output 4
10: Branch output 5
20: Branch output 6
40: Branch output 7
80: Branch output 8
02 Startup Always set to 00.
03 Shutdown Always set to 00.
04 Reset switch Always set to 00.
10 Clear peak output
current
Each bit corresponds to a branch output.
(Multiple branch outputs can be specified.)
01: Branch output 1
02: Branch output 2
04: Branch output 3
08: Branch output 4
10: Branch output 5
20: Branch output 6
40: Branch output 7
80: Branch output 8
To Next Page
