22
Specifications Section 2-3
2-3 Specifications
Ratings and Characteristics
S8AS-24006@
Item Model S8AS-24006 S8AS-24006N S8AS-24006R
Efficiency (Typ.) 80% min.
Input
condi-
tions
Voltage range (See note 1.) 100 to 240 VAC (85 to 264 VAC)
Frequency (See note 1.) 50/60 Hz (47 to 63 Hz)
Current 100-V input 3.8 A max.
200-V input 2.0 A max.
Power factor 0.95 min.
Harmonic current EN61000-3-2
Leakage cur-
rent
100-V input 0.5 mA max.
200-V input 1.0 mA max.
Inrush current
(See note 2.)
100-V input 25 A max. (for a cold start at 25°C)
200-V input 50 A max. (for a cold start at 25°C)
Output
condi-
tions
Number of branches 6
Maximum cutoff output current
(per branch)
3.8 A
Total output current 10 A
Allowable voltage range (See
note 3.)
±10 A (with V.ADJ)
Ripple noise voltage 2.0%[P-P] max. (for rated input and output voltage) (See note 4.)
Output leakage current 10 mA max.
Input fluctuation 0.5 % max. (Input: 85 to 264 VAC, 100 % load) (See note 5.)
Load fluctuation (rated input
voltage)
4.0 % max. (rated input, 0% to 100% load) (See note 5.)
Temperature fluctuation 0.05%/°C max.
Startup time (See note 2.) 3,000 ms max. (for rated input and output voltage) (See note 4.)
Output hold time (See note 2.) 20 ms min. (for rated input and output voltage) (See note 4.)
Func-
tions
Tripping func-
tions
Abnormal volt-
age tripping
28.8 V (Cannot be changed.)
Abnormal cur-
rent tripping
(See note 2.)
Setting range: 0.5 to
3.8 A (in 0.1-A incre-
ments)
3.8 A (Cannot be
changed.)
Setting range: 0.5 to
3.8 A (in 0.1-A incre-
ments)
Abnormal total
current tripping
Branch outputs are cut off when the total output current is more than 17 A for
2 s, 15 A for 5 s, 13 A for 10 s, or 12 A for 20 s.
Tripping Alarm
Output
Photoswitch output
30 VDC max. and 50 mA max., Leakage current: 0.1 mA max., Residual volt-
age: 2 V max.
Undervolt-
age detec-
tion functions
Undervoltage
detection
Setting range: 18.0 to
26.4 V (in 0.1-V incre-
ments)
20.0 V (Cannot be
changed.)
Setting range: 18.0 to
26.4 V (in 0.1-V incre-
ments)
Undervoltage
detection out-
put
Photoswitch output
30 VDC max. and 50 mA max., Leakage current: 0.1 mA max.,
Residual voltage: 2 V max.
Maintenance
forecast mon-
itor function
Maintenance
forecast moni-
tor
Setting range: 0.0 to
5.0 yr (in 0.5-yr incre-
ments)
0.5 yr (Cannot be
changed.)
Setting range: 0.0 to
5.0 yr (in 0.5-yr incre-
ments)
Maintenance
forecast moni-
tor output
Photoswitch output
30 VDC max. and 50 mA max., Leakage current: 0.1 mA max.,
Residual voltage: 2 V max.
To Next Page
