26
Specifications Section 2-3
Func-
tions
Over-tempera-
ture detection
function
Over-tem-
perature
threshold
Setting range: 25 to 90°C
(in 1°C increments)
90°C (Cannot be
changed.)
Setting range: 25 to 90°C
(in 1°C increments)
Over-tem-
perature
output
Photoswitch output
30 VDC max. and 50 mA max., Leakage current: 0.1 mA max.,
Residual voltage: 2 V max.
Display func-
tions
Output volt-
age
display
Display range: 17.0 to 30.0 V
Display accuracy: 2% rdg ±1 digit max.
Output cur-
rent display
Branch output display range: 0.0 to 4.0 A
Peak output current display range: 0.0 to 20.0 A
Total current display range: 0.0 to 40.0 A
Display accuracy: 5% FS (4 A) ±1 digit max.
Mainte-
nance fore-
cast monitor
display
Display range: FUL (Full)/HLF (Half)/0.0 to 5.0 yr
Tempera-
ture display
Display range: −20 to 100°C
Display accuracy: 2°C ±1 digit max.
External Tripping Input The input can be enabled
or disabled for each
branch output.
19.2 to 30 VDC, minimum
signal width: 10 ms,
tripping after input within
20 ms + the shutdown
sequence set time
All branch outputs:
Enabled (Cannot be
changed.)
19.2 to 30 VDC, minimum
signal width: 10 ms,
tripping after input within
20 ms + the shutdown
sequence set time
The input can be enabled
or disabled for each
branch output.
19.2 to 30 VDC, minimum
signal width: 10 ms,
tripping after input within
20 ms + the shutdown
sequence set time
Startup sequence Setting range: 0.0 to
99.9 s in 0.1-s increments
Branch output 1: 0.0 s
(Cannot be changed.)
Branch output 2: 0.4 s
(Cannot be changed.)
Branch output 3: 0.8 s
(Cannot be changed.)
Branch output 4: 1.2 s
(Cannot be changed.)
Branch output 5: 1.6 s
(Cannot be changed.)
Branch output 6: 2.0 s
(Cannot be changed.)
Branch output 7: 2.4 s
(Cannot be changed.)
Branch output 8: 2.8 s
(Cannot be changed.)
Setting range: 0.0 to
99.9 s in 0.1-s incre-
ments
Shutdown sequence Setting range: 0.0 to
99.9 s in 0.1-s increments
All branch outputs:
0.0 s (Cannot be
changed.)
Setting range: 0.0 to
99.9 s in 0.1-s incre-
ments
Communications Not supported Supported (RS-485)
Sampling period 1 ms
Parallel connection Not supported.
Series connection Not supported.
Item Model S8AS-48008 S8AS-48008N S8AS-48008R
