4-14
CHAPTER 4 Adjustment
Fig. 4-9
Base rear cover 2
Base rear cover 1
Y-axis upper cover
X-axis upper cover
Base front cover
X-axis under cover
Y-axis under cover
t M3×6 (with washer)
r M4×6
q M4×6
w M4×6
y M3×50
u M4×6
e M4×6
