5-60
CHAPTER 5 Periodic Inspection
11) Attach the clamp plate to the top of the bellows.
12) Fit O-rings 4, 10, 16 into the O-ring grooves on the robot body.
13) Attach the bellows to the spline shaft. A little bit large force is required due
to O-rings, but fully insert the bellows all the way into the position. (Refer
to Fig, 5-53 for installation height.)
14) Tighten bolts 1, 7, 13 to secure the bellows top clamp plate.
15) Rotate the bellows bottom clamp plates to correct a twist in the bellows.
16) Tighten set screws 3, 9, 15 on the bellows bottom clamp plate. (There are 2
pieces each.)
17) Reattach the end effector.
18) Go outside the safeguard enclosure.
19) Check that no one is inside the safeguard enclosure, and then turn on the
controller.
CAUTION
USE CAUTION NOT TO LET O-RINGS TO PROTRUDE FROM THEIR
GROOVES AND BE PINCHED. IF THE ROBOT IS OPERATED WHILE AN
O-RING IS STILL PINCHED, THE CLEANLINESS DEGREE MAY
DEGRADE.
CAUTION
USE CAUTION NOT TO LET O-RINGS TO PROTRUDE FROM THEIR
GROOVES AND BE PINCHED. IF THE ROBOT IS OPERATED WHILE AN
O-RING IS STILL PINCHED, THE CLEANLINESS DEGREE MAY
DEGRADE.
