No.19S185-01
17/68
STC-MBE132POE / STC-MCE132POE
Product Specifications and User’s Guide
1) Frame Trigger Wait
The condition of camera operation with trigger signal can be check.
“LOW” state of signal is out between “start exposing” to “image out”.
2) Frame Trigger Internal
The input trigger signal with the trigger delay (camera internal process delay).
3) Exposure Active
While camera exposing, “HIGH” state of signal is out. The signal state will be “LOW” after finish
exposing.
4) Acquisition Trigger Wait
While image transferring from camera to PC, “Low” state of signal is out. The signal state will be
“High” after finish image transferring.
5) Acquisition Trigger Internal
The image transferring starts signal is out.
6) Sensor Read Out
FVAL (Frame valid, HIGH state) signal is out.
7) Debounced Line0
Debounced Line0 signal is out.
8) Debounced Line2
Debounced Line2 signal is out.
9) User Output 1 (User Output signal through Line 1)
Selected “HIGH” or “LOW” state of signal is out.
10) User Output 2 (User Output signal through Line 2)
Selected “HIGH” or “LOW” state of signal is out.
11) Timer 0 Active
Selected signal at “Timer Counter” is out.
When signal synchronizing with “Exposure Active” signal, signal can use for strobe control.
12) Software Signal 0
Selected signal for “Software Signal 0” at “Software Signal Control” is out.
13) Software Signal 1
Selected signal for “Software Signal 1” at “Software Signal Control” is out.
14) Logic Block 0
“Logic Block 0” signal is out.
15) Pulse Per Second
“Pulse / second” signal (50% Duty, 1 Hz interval) is out.
