No.19S185-01
63/68
STC-MBE132POE / STC-MCE132POE
Product Specifications and User’s Guide
11.12 ChunkDataControl
Name Description
ChunkModeActive Activates the inclusion of Chunk data in the payload of the image.
ChunkSelector Selects which Chunk to enable or control.
ChunkEnable [ChunkSelector] Enables the inclusion of the selected Chunk data in the payload of the
image.
ChunkCounterSelector Selects which counter to retrieve data from.
ChunkCounterValue
[ChunkCounterSelector]
Returns the value of the selected Chunk counter.
ChunkGainSelector Selects which Gain to return.
ChunkGain [ChunkGainSelector] Returns the gain used to capture the image.
ChunkExposureTimeSelector Selects which Exposure Time to return.
ChunkExposureTime
[ChunkExposureTimeSelector]
Returns the exposure time used to capture the image.
ChunkBlackLevelSelector Selects which Black Level to return.
ChunkBlackLevel
[ChunkBlackLevelSelector]
Returns the black level used to capture the image included in the
payload.
ChunkLineStatusAll Returns the status of all the I/O lines at the time of the Frame Start
internal event.
ChunkTimerSelector Selects which timer to retrieve data from.
ChunkTimerValue
[ChunkTimerSelector]
Returns the value of the selected Timer.
ChunkDeviceTemperature Indicates the value of the temperature when the image was acquired.
11.13 ActionControl
Name Description
ActionDeviceKey Provides the device key that allows the device to check the validity of
action commands.
ActionQueueSize Indicates the size of the scheduled action commands queue.
ActionSelector Selects to which Action Signal further Action settings apply.
ActionGroupMask [ActionSelector] Provides the mask that the device will use to validate the action on
reception of the action protocol message.
ActionGroupKey [ActionSelector] Provides the key that the device will use to validate the action on
reception of the action protocol message.
