No.19S185-01
39/68
STC-MBE132POE / STC-MCE132POE
Product Specifications and User’s Guide
AGC (Auto Gain Contorl)
The brightness of image maintains to keep target brightness with gain automatically.
If the brightness of image is darker than target brightness, gain increases up to “Gain Auto Limit Max”.
If the brightness of image is brighter than target brightness, gain decreases.
GenICam Parameters
GainSelector IEnumeration Type Adjustable gain selection
Selected gain can be adjusting by Gain[GainSelector].
Please select “Analog All” when AGC is turned on.
Selection: “Analog All” (analog gain) and “Digital All” (digital gain)
Default: “Analog All”
Gain[GainSelector] IFloat Type Gain
Selected gain at “Gain Selector” is adjusting
Analog gain:
Range: 0 to 2
Default: 0
Digital gain:
Range: 0 to 255
Default: 0
Analog gain cannot adjustable when AGC is turned on.
GainAuto
[GainSelector]
IEnumeration Type AGC ON / OFF selection
Selection: “ON” (Continuous) and “OFF” (Off)
Default: OFF
GainAutoLimitMin
[GainSelector]
IFloat Type Minimum gain for AGC
Range: 0 to 208
Default: 0
This cannot be set greater than “Gain Auto Limit Max”
GainAutoLimitMax
[GainSelector]
IFloat Type Maximum gain for AGC
Range: 0 to 208
Default: 208
This cannot be set smaller than “Gain Auto Limit Min”
