Omron STC-MBE132POE User Manual

No.19S185-01
11/68
STC-MBE132POE / STC-MCE132POE
Product Specifications and User’s Guide
5 Specifications
5.1 Electronic Specifications
Product STC-MBE132POE STC-MCE132POE
Image Sensor 1/1.8” 1.3M Progressive Monochrome CMOS
(e2V: EV76C560)
1/1.8” 1.3M Progressive Color CMOS
(e2V: EV76C560)
Shutter Type Global Shutter / Rolling Shutter
Active Picture Elements 1,280 (H) x 1,024 (V)
Cell Size 5.3 (H) x 5.3 (V) µm
Scanning Mode
Full scanning (Full resolution) / ROI
Frame rate (at full scanning)
8bits: 61.0 fps / 10bits: 41.9 fps / 10bits Packed: 55.9 fps / RGB8: 27.9 fps
ADC bit depth 10bits
Image Output Format (*1)
Mono8 / Mono10 / Mono10Packed
Mono8 / Mono10 / Mono10Packed /
BayerBG8 / BayerBG10 / BayerBG10Packed /
RGB8
Noise
Level
8bits output Less than 3 digits (Gain 0 dB)
10bits / 10bits Packed output Less than 12 digits (Gain 0 dB)
Sensitivity (*2) 460 Lux 900 Lux
Exposure Time
10 µseconds to 1.0300 seconds (Default: 16,379 µseconds)
Gain Analog Gain
x1 to x2 (Default: x1)
Digital Gain
x1 to x3 (Default: x1)
ROI
Horizontal: 8 to 1,280 pixels, Vertical: 2 to 1,024 lines (Default: 1,280 x 1,024)
Adjustable steps for size: 8 pixels in horizontal direction and 2 lines in vertical direction
Adjustable steps for offset: 8 pixels in horizontal direction and 2 lines in vertical direction
Gamma
Gamma 0.1 to 4.0 (Default: 1.0)
Binning
Horizontal x2, x4 and Vertical x2, x4 binning / Off
Decimation
Horizontal and Vertical binning (2x2) / Off
Image Flip
Horizontal / Vertical / Horizontal and Vertical / Off
Defective Pixel Correction
Up to 2,048 points (Default: On)
Auto
Control
Auto Exposure
Support (Default: OFF)
Auto Gain
Support (Default: OFF)
Auto White Balance N/A Support
Operational Mode
Edge preset trigger / Free run
Interface PoE: IEEE802.3af CLASS2 (1000BASE-T)
Protocol GigE Vision 2.1 and GenICam SFNC 2.4, IEEE1588 (PTP)
I/O One opto-isolated input, one opto-isolated output and one open collector GPIO (Input or output)
Power Input Voltage (*3) +10.8 to +26.4 Vdc External power (via 6 pin connector) /
Power Over Ethernet (IEEE802.3af)
Consumption +12 V / +24 V: 3.0 W, PoE: 3.1 W
Default: Bold

Omron STC-MBE132POE Specifications

General

Brand	Omron
Model	STC-MBE132POE
Category	Digital Camera
Language	English
