11.7 LogicBlockControl
Name Description
LogicBlockSelector Specifies the Logic Block to configure.
LogicBlockFunction [LogicBlockSelector] Selects the combinational logic Function of the Logic Block to
configure.
LogicBlockInputNumber
[LogicBlockSelector]
Specifies the number of active signal inputs of the Logic Block.
LogicBlockInputSelector
[LogicBlockSelector]
Selects the Logic Block’s input to configure.
LogicBlockInputSource
[LogicBlockSelector]
[LogicBlockInputSelector]
Selects the source signal for the input into the Logic Block.
LogicBlockInputInverter
[LogicBlockSelector]
[LogicBlockInputSelector]
Selects if the selected Logic Block Input source signal is inverted.
11.8 SoftwareSignalControl
Name Description
SoftwareSignalSelector Selects which Software Signal features to control.
SoftwareSignalPulse
[SoftwareSignalSelector]
Generates a pulse signal that can be used as a software trigger.
11.9 CounterAndTimerControl
Name Description
CounterSelector Selects which Counter to configure.
CounterEventSource [CounterSelector] Select the events that will be the source to increment the Counter.
CounterResetSource [CounterSelector] Selects the signals that will be the source to reset the Counter.
CounterResetActivation [CounterSelector] Selects the Activation mode of the Counter Reset Source signal.
CounterReset [CounterSelector] Does a software reset of the selected Counter and starts it.
CounterValue [CounterSelector] Reads or writes the current value of the selected Counter.
TimerSelector Selects which Timer to configure.
TimerDuration [TimerSelector] Sets the duration (in microseconds) of the Timer pulse.
TimerDelay [TimerSelector] Sets the duration (in microseconds) of the delay to apply at the
reception of a trigger before starting the Timer.
TimerTriggerSource [TimerSelector] Selects the source of the trigger to start the Timer.
TimerTriggerActivation [TimerSelector] Selects the activation mode of the trigger to start the Timer.
TimerValue [TimerSelector] Reads or writes the current value (in microseconds) of the selected
Timer.
