No.19S185-01
57/68
STC-MBE132POE / STC-MCE132POE
Product Specifications and User’s Guide
11.2 ImageFormatControl
Name Description
SensorWidth Effective width of the sensor in pixels.
SensorHeight Effective height of the sensor in pixels.
SensorShutterMode Sets the shutter mode of the device.
WidthMax Maximum width of the image (in pixels).
HeightMax Maximum height of the image (in pixels).
BinningSelector Selects which binning engine is controlled by the Binning Horizontal
and Binning Vertical features.
BinningHorizontalMode [BinningSelector] Sets the mode to use to combine horizontal photo-sensitive cells
together when Binning Horizontal is used.
BinningVerticalMode [BinningSelector] Sets the mode used to combine vertical photo-sensitive cells together
when Binning Vertical is used.
BinningHorizontal [BinningSelector] Number of horizontal photo-sensitive cells to combine together.
BinningVertical [BinningSelector] Number of vertical photo-sensitive cells to combine together.
DecimationHorizontal Horizontal sub-sampling of the image.
DecimationVertical Vertical sub-sampling of the image.
RegionSelector Selects the Region of interest to control.
RegionMode [RegionSelector] Controls if the selected Region of interest is active and streaming.
Width [RegionSelector] Width of the image provided by the device (in pixels).
Height [RegionSelector] Height of the image provided by the device (in pixels).
OffsetX [RegionSelector] Horizontal offset from the origin to the region of interest (in pixels).
OffsetY [RegionSelector] Vertical offset from the origin to the region of interest (in pixels).
PixelFormat Format of the pixels provided by the device.
PixelSize Total size in bits of a pixel of the image.
PixelColorFilter Type of color filter that is applied to the image.
ReverseX Flip horizontally the image sent by the device.
ReverseY Flip vertically the image sent by the device.
TestPatternGeneratorSelector Selects which test pattern generator is controlled by the Test Pattern
feature.
TestPattern
[TestPatternGeneratorSelector]
Selects the type of test pattern that is generated by the device as
image source.
TestPatternInputValue
[TestPatternGeneratorSelector]
Test Pattern Input Value
To Next Page
