3-2 Wiring
3-2-1 Terminal Blocks
Name of Each Terminal Block
Main Circuit Terminals (Input)
Power input
terminals
Braking resistor
connection terminals
Transmission
terminals
Main Circuit Terminals (Output)
Control circuit
terminals
Ground
terminal
Motor output terminals
Note
This diagram shows an Inverter with all terminal block covers removed.
