6-1 Specifications of Main Unit
Rating
3G3EV model
Three-phase input A2001R A2002R A2004R A2007R A2015R
Single/Three-phase
input
AB001R AB002R AB004R AB007R ---
Maximum applicable motor capacity
(kW)
0.1 0.2 0.4 0.75 1.5
Rated
Rated output capacity (kVA) 0.3 0.6 1.1 1.9 2.6
output
Rated output current (A) 0.8 1.5 3.0 5.0 7.0
Rated output voltage (V) Three-phase 200 to 230 V (depending on input
voltage)
Maximum frequency (Hz) 400 Hz (set in constant No. 24)
Power
supply
Rated voltage and frequency 3G3EV-A2
R (three-phase input):
Three-phase, 200 to 230 VAC, 50/60 Hz
3G3EV-AB
R (three-phase input):
Three-phase, 200 to 230 VAC, 50/60 Hz
3G3EV-AB
R (single-phase input):
Single-phase, 200 to 240 VAC, 50/60 Hz
Allowable voltage fluctuation --15% to +10%
Allowable frequency
fluctuation
±5%
Cooling method Self-cooling
General Specifications
Installation type Panel mounting
Installation site Indoor (free from corrosive gases and dust)
Ambient temperature for
operation
--10° to 50°C
Humidity 90% or less (no-condensing)
Ambient temperature for storage --20° to 60°C
Altitude 1,000 m max.
Vibration resistance Less than 20 Hz: 1G {9.8 m/s
2
}orless
20 to 50 Hz: 0.2G {1.96 m/s
2
}orless
Cable length between Inverter
and motor
100 m max.
Chapter 6
