Constant
no.
Dedicated
indicator
Description Setting range Factory setting
n04 Forward/Reverse rotation
selection
For, rEv For
n06 Multi-function input selec-
tion 1
0to14 1
n07 Multi-function input selec-
tion 2
1to14 2
n08 Multi-function input selec-
tion 3
1to15 4
n09 Multi-function output selec-
tion 1
0to11 1
n10 Multi-function output selec-
tion 2
0to11 2
n11 Frequency reference 1 0.0 to 400 6.0 (Hz)
n12 Frequency reference 2 0.0 to 400 0.0 (Hz)
n13 Frequency reference 3 0.0 to 400 0.0 (Hz)
n14 Frequency reference 4 0.0 to 400 0.0 (Hz)
n15 Frequency reference 5 0.0 to 400 0.0 (Hz)
n16 Frequency reference 6 0.0 to 400 0.0 (Hz)
n17 Frequency reference 7 0.0 to 400 0.0 (Hz)
n18 Frequency reference 8 0.0 to 400 40.0 (Hz)
n20 Acceleration time 1 0.0 to 999 10.0 (seconds)
n21 Deceleration time 1 0.0 to 999 10.0 (seconds)
n22 Acceleration time 2 0.0 to 999 10.0 (seconds)
n23 Deceleration time 2 0.0 to 999 10.0 (seconds)
n24 Maximum frequency 50.0 to 400 60.0 (Hz)
n25 Maximum voltage 1to255 200 (V)
n26 Maximum voltage frequency 1.6 to 400 60.0 (Hz)
n31 Electronic thermal reference
current
0.0 or more
(see note 1)
See note 1
n33 Stall prevention during de-
celeration
0, 1 0
n36 Operation after recovery
from power interruption
0, 1, 2 0
n37 Carrier frequency 1, 2, 3, 4 4
n50 Over-torque detection func-
tion selection
0to4 0
