C1000H(F) and C2000(H)
Word no.
n67
Base no. 0
Base no. 1 Base no. 2
Base no. 3
n n+1 n n+1 n n+1 n n+1
0 0 1 32 33 64 65 96 97
1 2 3 34 35 66 67 98 99
2 4 5 36 37 68 69 100 101
3 6 7 38 39 70 71 102 103
4 8 9 40 41 72 73 104 105
5 10 11 42 43 74 75 106 107
6 12 13 44 45 76 77 108 109
7 14 15 46 47 78 79 110 111
8 16 17 48 49 80 81 112 113
9 18 19 50 51 82 83 114 115
10 20 21 52 53 84 85 116 117
11 22 23 54 55 86 87 118 119
12 24 25 56 57 88 89 120 121
13 26 27 58 59 90 91 122 124
14 28 29 60 61 92 93 124 125
15 30 31 62 63 94 95 126 127
CV500, CV1000, and CVM1
•
For the SYSMAC BUS remote I/O relay area, 32 words are allocated to each RM ad-
dress (RM0 to RM7) starting with word 2300, by default.
RM address
RM0 RM1 RM2 RM3 RM4 RM5 RM6 RM7
Allocated
words
2300 to
2331
2332 to
2363
2364 to
2395
2396 to
2427
2428 to
2459
2460 to
2491
2492 to
2523
2524 to
2555
•
RM addresses are automatically assigned in the order in which Remote I/O Master
Units were installed (or Rack numbers were set). This happens when an I/O table is
created or edited.
Chapter 4
