Omron SYSDRIVE 3G3JV Series User Manual

2-6
H Ambient T emperature Control
•To enhance operation reliability , the Inverter should be installed in an environment free
from extreme temperature changes.
•If
the Inverter is installed in an enclosed environment such as a box, use a cooling fan
or air conditioner to maintain the internal air temperature below 50°C.
The
life of the built-in electrolytic capacitors of the Inverter is prolonged by maintaining
the internal air temperature as low as possible.
•The
surface temperature of the Inverter may rise approximately 30 ° C higher than the
ambient temperature. Be sure to keep away equipment and wires from the Inverter as
far as possible if the equipment and wires are easily influenced by heat.
H Protecting Inverter from Foreign Matter during Installation
•Place a cover over the Inverter during installation to shield it from metal power pro-
duced by drilling.
Upon
completion of installation, always remove the cover from the Inverter . Otherwise,
ventilation will be affected, causing the Inverter to overheat.
Design Chapter 2

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
