Omron SYSDRIVE 3G3JV Series User Manual

H Contents of Warning
S For 3G3JV-A2001 to A2007 (0.1 to 0.75 kW)/3G3JV-AB001 to AB004 (0.1 to
0.4 kW)
S For 3G3JV-A2015 to A2022 (1.5 to 2.2 kW)/3G3JV-AB007 to AB015 (0.75 to
1.5 kW)
Checking Before Unpacking
H Checking the Product
On delivery , always check that the delivered product is the SYSDRIVE 3G3JV Inverter
that you ordered.
Should
you find any problems with the product, immediately contact your nearest local
sales representative.
D Checking the Nameplate
Inverter model
Input specifications
Output specifications
D Checking the Model
3G3JV-A2007 N Z 00001
Special software option
No Heatsink
No potentiometer
Maximum applicable motor capacity
Voltage class
Installation type
Series name: 3G3JV Series

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
