Omron SYSDRIVE 3G3JV Series User Manual

Installation Type
A Closed wall mounting
Voltage Class
2 Three-phase 200-VAC input
(200-V class)
B Single-phase 200-VAC input
(200-V class)
Maximum Applicable Motor Capacity
001 0.1 (0.1) kW
002 0.2 (0.25) kW
004 0.4 (0.55) kW
007 0.75 (1.1) kW
015 1.5 (1.5) kW
022 2.2 (2.2) kW
Note The figures in parentheses indicate capacities for motors used outside Japan.
Front Cover options
B Blank cover
N No potentiometer
Heatsink option
Z No Heatsink
Software options
0001 – 99999 Special software
option
D Checking for Damage
Check the overall appearance and check for damage or scratches resulting from trans -
portation.
H Checking the Accessories
Note that this manual is the only accessory provided with the 3G3JV. Set screws and
other necessary parts must be provided by the user.

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
