D Single-phase 200-VAC Model
Model
3G3JV-
Terminal symbol Termi-
nal
screw
Terminal
torque
(NSm)
Wire
size
(mm
2
)
Recom-
mended
wire
size
(mm
2
)
Circuit
breaker
capac-
ity (A)
AB001
R/L1, S/L2, T/L3, –, +1,
+2, U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 5
AB002
R/L1, S/L2, T/L3, –, +1,
+2, U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 5
AB004
R/L1, S/L2, T/L3, –, +1,
+2, U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 10
AB007
R/L1, S/L2, T/L3, –, +1,
+2, U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 2 to 5.5
3.5
20
2
AB015
R/L1, S/L2, T/L3, –, +1,
+2, U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 2 to 5.5
5.5
20
2
