25
Outputs
1.6 kΩ (1/2 W)
Original adjustment command
output
0 V
Constant-
voltage
circuit
A1
B2
1.6 k
Ω (1/2 W)
A3
B3
A4
B4
A5
B5
A6
B6
A7
B7
Power for output, 24 VDC
Power for output, 5 VDC
CCW pulse output/direction output (w/1.6 kΩ
resistor)
CCW pulse output/direction
output
Note: The CW/CCW pulse outputs or the
pulse/direction outputs can be selected by
the DIP switch on the rear panel.
CW pulse output/pulse (CW+CCW) out-
put (w/1.6 kΩ resistor)
CW pulse output/pulse (CW+CCW)
output
0 V
0 V
Deviation counter reset output
0 V
Provide a power supply of either
5 or 24 VDC.
The internal circuit will be
damaged if both the 5 and 24
VDC power sources are
connected.
Wiring Section 2–2
