Motor Slip Compensation: C3
Param
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
C3-01
Slip compen-
sation gain
Used to improve speed accuracy
when operating with a load.
Usually changing this setting is not
necessary.
Adjust this parameter under the fol-
lowing circumstances.
• When motor speed is lower than
the frequency reference increase
the set value.
• When motor speed is higher than
the frequency reference decrease
the set value.
In Closed Loop Vector control this
value is the gain for compensating
the slip caused by temperature varia-
tion.
0.0 to
2.5
1.0 Yes - A A - 20FH 6-29
Slip Comp
Gain
C3-02
Slip compen-
sation delay
time
Sets the Slip Compensation delay
time.
Usually changing this setting is not
necessary.
Adjust this parameter under the fol-
lowing circumstances.
• Reduce the setting when Slip
Compensation responsiveness is
low.
• When speed is not stable, increase
the setting.
0 to
10000
2000
ms
No - A - - 210H 6-29
Slip Comp
Time
C3-03
Slip compen-
sation limit
Sets the slip compensation limit as a
percentage of motor rated slip.
0 to
250
200% No - A - - 211H 6-29
Slip Comp
Limit
C3-04
Slip compen-
sation selec-
tion during
regeneration
0:Disable
1:Enabled
When the slip compensation during
regeneration function has been acti-
vated and regeneration capacity
increases momentarily, it might be
necessary to use a braking option
(braking resistor, braking resistor
unit or braking unit.)
0 or 1 1 No - A - - 212H 6-29
Slip Comp
Regen
C3-05
Output volt-
age limit
operation
selection
0:Disabled
1:Enabled. (The motor flux will be
lowered automatically when the
output voltage become saturated.)
0 or 1 1 No - A A - 213H 6-29
Output V
limit Sel
