Omron VARISPEED L7 User Manual

5-15
5
Torque Compensation: C4
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
C4-01
Torque compen-
sation gain
Sets the torque compensation
gain.
Usually changing this setting is
not necessary.
Adjust it under the following
circumstances:
• When the cable is long
increase the set value.
• When the motor capacity is
smaller than the Inverter
capacity (Max. applicable
motor capacity), increase the
set values.
• When the motor is oscillat-
ing, decrease the set values.
Adjust the torque compensation
gain so that at minimum speed
the output current does not
exceed the Inverter rated output
current.
Do not change the torque com-
pensation gain from its default
(1.00) when using Open Loop
Vector control.
0.00 to
2.50
1.00 Yes A A - - 215H 6-30
Torq Comp Gain
C4-02
Torque compen-
sation delay time
constant
The torque compensation delay
time is set in ms units.
Usually changing this setting is
not necessary.
Adjust it under the following
circumstances:
• When the motor is oscillat-
ing, increase the set values.
• When the responsiveness of
the motor is low, decrease
the set values.
0 to
10000
i
No
200
ms
50 ms - - 216H 6-30
Torq Comp Time
C4-03
Starting torque
compensation
(FWD)
Sets the torque compensation
value at start in FWD direction
0.0 to
200.0%
0.0% No - A - - 217H 6-30
FTorqCmp @
Start
C4-04
Starting torque
compensation
(REV)
Sets the torque compensation
value at start in REV direction
-
200.0%
to 0.0
0.0% No - A - - 218H 6-30
RTorqCmp @
Start
C4-05
Starting torque
compensation
time constant
Sets starting torque start-up
time.
When 0 ~ 4 ms is set, it is oper-
ated without filter.
0 to 200 10 ms No - A - - 219H 6-30
TorqCmpDelayT
