Omron VARISPEED L7 User Manual

5-6
5
E1-04
Max. output fre-
quency (FMAX)
Sets the output voltage of the base fre-
quency (E1-06).
40.0 to
120.0
i
No
50.0
Hz
50.0
Hz
50.0
Hz
-
303H
Max Frequency
(with
PG-F2)
0 to
1200
-- -
150
rpm
(with
PG-X2)
0 to
3600
E1-05
Max. voltage
(VMAX)
0.0 to
510.0
*2
380.0 V
*2
No Ye s Yes Ye s No 30 4H
Max Voltage
E1-06
Base frequency
(FA)
0.0 to
120.0
i
No
50.0
Hz
50.0
Hz
50.0
Hz
-
305H
Base Frequency
(with
PG-F2)
0 to
1200
-- -
150
rpm
(with
PG-X2)
0 to
3600
E1-08
Mid. output fre-
quency voltage
(VB)
0.0 to
510
*2
i
No
37.3
V
*2
25.0
V
*2
- - 307H
Mid voltage A
E1-09
Min. output fre-
quency (FMIN)
0.0 to
120.0
i
No
0.5
Hz
0.3
Hz
- - 308H
Min Frequency
E1-10
Min. output fre-
quency voltage
(VMIN)
0.0 to
510.0
*2
i
No
19.4
V
*2
5.0 V
*2
- - 309H
Min Voltage
E1-13
Base voltage
(VBASE)
0.0 to
510.0
*2
i
No
0.0 V 0.0 V
-
-
30CH
Base Voltage - - 400 V
E2-01
Motor rated current
Sets the motor rated current in Amps.
This set value becomes the base value
for motor protection and torque limit. It
is an input data for autotuning.
0.85 to
17.00
*3
7.00 A
*4
No Ye s Yes Ye s - 3 0EH
Mtr Rated Current
E2-02
Motor rated slip
Sets the motor rated slip.
This set value will become the reference
value for the slip compensation.
This parameter is automatically set dur-
ing autotuning.
0.00 to
20.00
2.70 Hz
*4
No Ye s Yes Ye s - 3 0F H
Motor Rated Slip
E2-03
Motor no-load cur-
rent
Sets the motor no-load current.
This parameter is automatically set dur-
ing autotuning.
0.00 to
6.99
2.30 A
*4
No Ye s Yes Ye s - 31 0H
No-Load Current
E2-04
Number of motor
poles
Sets the number of motor poles. It is an
input data for autotuning.
2 to 48 4 No - - Yes - 311H
Number of Poles
E2-05
Motor line-to-line
resistance
Sets the motor phase-to-phase resis-
tance.
This parameter is automatically set dur-
ing autotuning.
0.000
to
65.000
3.333 Ω
*4
No Ye s Yes Ye s - 31 2H
Term Resistance
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
