DIP switches and straps of the Crocus CNV Crocus CNV
40 User manual
DIP switch bank DS3
The following table gives an overview of the DIP switches on DIP switch bank DS3:
DIP switch name DS3 no. Setting Function
on The receive B signal (RxB) of the
onboard G703 interface of
converter A is connected to the
earth.
1
off
The receive B signal (RxB) of the
onboard G703 interface of
converter A is disconnected from
the earth.
on The transmit B signal (TxB) of the
onboard G703 interface of
converter A is connected to the
earth.
signal B – earth
(PGND) connection
for converter A
2
off
The transmit B signal (TxB) of the
onboard G703 interface of
converter A is disconnected from
the earth.
DIP switch bank DS4
The following table gives an overview of the DIP switches on DIP switch bank DS4:
DIP switch name DS4 no. Setting Function
on The receive B signal (RxB) of the
onboard G703 interface of
converter B is connected to the
earth.
1
off
The receive B signal (RxB) of the
onboard G703 interface of
converter B is disconnected from
the earth.
on The transmit B signal (TxB) of the
onboard G703 interface of
converter B is connected to the
earth.
signal B – earth
(PGND) connection
for converter B
2
off
The transmit B signal (TxB) of the
onboard G703 interface of
converter B is disconnected from
the earth.
