DIP switches and straps of the Crocus CNV Crocus CNV
36 User manual
3.2 DIP switches and straps of the Crocus CNV Card Version
This section locates the DIP switches and straps on the Crocus CNV Card Version motherboard. It gives
an overview of their function and it explains how to change their settings.
The following table gives an overview of this section.
Section Title Page
3.2.1 Location of the DIP switches on the Card Version 37
3.2.2 Location of the straps on the Card Version 38
3.2.3 DIP switches of the Card Version 39
3.2.4 Straps of the Card Version 41
3.2.5 Changing DIP switch and strap settings of the Card Version 42
