10 TROUBLESHOOTING
10.1 WARNING AND ERROR MESSAGES
The PULSAR
2
console delivers warning and error messages on the LCD to inform the
operator of situations which may require special attention.
A window pops up in the middle of the LCD giving full explanation of the warning
or error, if operation can continue, an OK button appears on the window.
The operator must depress this button to confirm that the message has been
received. The pop up window will close and a small warning symbol will then
appear, as a reminder, on the warnings frame located on the right side of the LCD.
This reminder will automatically disappear when the cause of the warning has been
removed.
The table below summarizes the warning and error messages.
W
A
R
N
I
N
G
E
R
R
O
R
MESSAGE
X Err 01: Serial communication fault
X Err 02: Low input pressure
X Err 03: I/A Cassette missing
X Err 04: I/A Cassette full. Aspiration halted
X Err 06: Vacuum level error
X Err 07: US Power mismatch
X Err 08: Diathermy power mismatch
X Err 11: Vac offset
X Err 12: Major leakage
X Err 13: No irrigation
X Err 14: Aspiration occluded
X Err 15: Minor leakage
x Err 16: Low Ultrasounds power
X Priming interrupted by the user
X Err 19: Pressure level error
X Err 24: US enable/reading failure
X Err 25: US enable failure
X Err 26: Diath enable/reading failure
X Err 27: Diathermy enable failure
X Err 28: Footswitch failure
X Err 29: Watchdog failure
X Err 30: Power supply/reference mismatch
