continuous irrigation is activated, aspiration (and, eventually, cutting) starts
immediately, as the main paddle is slightly depressed, thus extending the available
travel for linear control.
In U/S mode, when the main paddle is depressed beyond detent #2 phaco
handpiece is activated, further depression of the paddle will increase the phaco
tip stroke (if linear control mode is on) or burst rate up to the preset level. If
continuous irrigation is activated, ultrasounds starts as the main paddle is
depressed beyond detent #1, thus extending the available travel for linear control.
In U/S mode, if both aspiration and phaco power are set in linear mode, then the
aspiration level will reach its maximum at about two thirds of the paddle travel,
then ultrasound are started and increased by depressing the paddle to full travel.
When the main paddle is rotated to the surgeon's left, the system swaps between
Memory 1, 2 and 3 in U/S mode, Memory 1 and 2 in DIATHERMY, I/A and VIT mode.
If the main paddle depressed at the heel (bottom) side, an immediate REFLUX
through the aspiration line of the connected handpiece occurs. REFLUX is a back
flow caused by the REFLUX valve opening allowing fresh BSS solution in the
aspiration line. A sound of low pitch (800 Hz) is heard.
Whenever the main paddle is depressed beyond detent #2 DIATHERMY, if selected,
is activated. If linear control mode is on, a further pressure on the paddle will
increase emission power level.
"CONTINUOUS IRRIGATION" switch reverses the state of the IRRIGATION valve which
if close opens, if open closes.
The Function change toggle switch allows to move from U/S to I/A mode and vice
versa or it allows switching from Vit mode to Diath or Sciss to Diath and vice versa.
Audible and visual feedbacks are provided as indication of selected modes, and
associated alarm conditions.
NOTE:
The Vacuum level is automatically reduced to zero whenever the footswitch is released.
8.7 TO RECALL OR STORE A PROGRAM
All default parameters of PULSAR
2
are independently adjustable to meet individual
requirements, they can be programmed by the user in the system memory, up to
100 programs can be stored, they are retained for approximately ten years.
The active program name is indicated in the Program Window, located on the
bottom part of the interface screen.
