ELECTROMAGNETIC IMMUNITY
GUIDANCE AND MANUFACTURER’S DECLARATION – ELECTROMAGNETIC IMMUNITY
The R-Evo Smart systems are intended for use in the electromagnetic environments
specified below. The customer or the user of the R-Evo Smart must ensure that it is used
in such an environment.
Test
of immunity
IEC 60601-1-2
Level of test
Compliance
level
Electromagnetic
environment
Electrostatic
discharge (ESD)
IEC 61000-4-2
+8 kV contact
± 2; 4; 8; 15 kV air
+8 kV contact
± 2; 4; 8; 15 kV air
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be
at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply lines
±1 kV for
input/output lines
100kHz
±2 kV for power
supply lines
±1 kV for
input/output lines
100kHz
Mains power quality should
be that of a typical
commercial or hospital
environment.
Surge
IEC 61000-4-5
±1 kV differential
mode
±2 kV common mode
±1 kV differential
mode
±2 kV common
mode
Mains power quality should
be that of a typical
commercial or hospital
environment.
Voltage dips,
short
interruptions
and voltage
variations on
power supply
input lines
IEC 61000-4-11
0% U
T
for 0.5 cycles
0 % U
T
for 1 cycle
70 % U
T
for 25 cycles
0 % U
T
for 250 cycles
0% U
T
for 0.5 cycles
0 % U
T
for 1 cycle
70 % U
T
for 25
cycles
0 % U
T
for 250
cycles
Mains power quality should
be that of a typical
commercial or hospital
environment. If the user of
the R-Evol Smart requires
continued operation during
power mains interruptions,
it is recommended that the
R-Evo Smart be powered
from an uninterruptible
power supply or a battery.
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
30 A/m
30 A/m
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
Note: UT is the a.c. mains voltage before the application of the test level
