systems. Training is provided by OPTIKON 2000 S.p.A.
Consult your OPTIKON 2000 S.p.A. technical service for
more detailed information.
It is the user's responsibility to clean and sterilize the
handpieces, tips and any other reusable microsurgical
accessory.
• Open the packaging of the medical device and its
accessories.
• Pull out the R-EVO SMART from its shipping packaging.
• Check the Instructions for Use when removing sterile
and resterilisable microsurgical accessories from the
packaging.
• For R-Evo Smart S and CR, check that the pressure
supply complies with the value indicated on the rear
panel (from 500 to 800 kPa - from 72.5 to 116 psi).
• For the R-Evo Smart S and CR, connect the compressed
air supply hose to the rear panel "GAS INLET" port and to
the wall compressed air supply line.
• Connect the pedal cord to the socket on the rear
panel of the R-Evo Smart.
• If you use the optional equipment cart with
instrument tray, connect the electric pole control
cable to the rear panel of the R-Evo Smart.
• Connect the AC power cord to the R-Evo Smart power
outlet.
• Connect the other end of the AC power cord to the wall
outlet.
Moving Your Device
If the optional tool trolley is used, it is equipped with a
handle which can be used to easily and safely transport
the Medical Device to a different installation location. Use
the handle for the purpose indicated.
CAUTION Risk of injury due to damage during movement
• If the tool is moved using the optional cart, if you
have to overcome a small step (max 3cm), push very
slowly using the handle.
Four locking tabs on the wheels make it easy to find the
installation position.
