Version 1.1.1 - 2021-1-2536 Translation of original instruction
MB4
EN
MB4_GB_5.fm
First after 200
operating
hours, then
every 2000
operating
hours
Gear of milling head
Oil change
For oil change use an appropriate collecting tray of suffi-
cient capacity.
Have the drilling-milling machine run for a few minutes, the
oil will heat up and will slightly penetrate from the opening.
Remove the oil drain plug.
Operating material on page 19
Abb.5-2: Milling head
Weekly
Drilling- milling machine
Oiling
Lubricate all oiler cups with machine oil, do not use grease
guns or the like.
Operating material on page 19
Img.5-3: Oiler cup
Every month
Oiler cup
Oiling
Lubricate all oiler cups with machine oil, do not use grease
guns or the like.
Interval Where? What? How?
Oil drain plug
Gear ventilation/
Filler hole
