The following table shows the alarms on the COMPACT screen:
COMPONENT
GENERATING
THE ALARM
TYPE OF ALARM
DESCRIPTION
RECOVERY
SYSTEM FAULT
Firmware error
Restart the unit.
SYSTEM FAULT
RECOVERED
This is not an alarm; instead, it is a
system fault recovery notification
If desired, you can delete this
notification. To accomplish this, carry
out the following from the unit that is
sending the notification:
1. Press  or  to display the alarms
tab ( ).
2. Use the navigation keys / to
view one of the alarms and press
OK.
3. Using the / keys, select the
RESET ALL FAULTS option.
4. Press OK.
ETH A
LINK FAIL
The connection to the unit's ETH A port
fails.
If the installation does not have a
redundant network, use the Call Point
software to disable the displaying of the
Ethernet Links alarm and send
configurations to the unit.
If the installation has a redundant
network, check the cable connection to
the ETH A port on the unit.
ETH B
LINK FAIL
The connection to the unit's ETH B port
fails.
If the installation does not have a
redundant network, use the Call Point
software to disable the displaying of the
Ethernet Links alarm and send
configurations to the unit.
If the installation has a redundant
network, check the cable connection to
the ETH B port on the unit.
NETWORK
ERROR
The unit does not respond to a network
ping.
Check the connection of the unit to the
Ethernet network. If the connection is
correct, check the network.
ROUTING ERROR
COMPACT units that allow routing
communications in the system do not
operate properly.
MAIN POWER
POWER FAIL
Indicates a failure of the primary power
to the COMPACT.
Check the primary power by ensuring
the COMPACT is receiving 24 VDC
through the POWER SUPPLY 1 terminal
strip (see figure 3, number 8).
