15. TECHNICAL CHARACTERISTICS
COMPACT. TABLE I
Slots
10
Slots occupied
2 (slot 1: UMX-C16, slot 2: UMX-EA3)
Slots free
8 (slots 3 to 10)
Ethernet communication
2 Ethernet connections (RJ45) A and B for redundant installations. IP Layer 3 & Layer 4
Network.
CAN Bus
Communication with the COMPACT-E slave matrix and peripherals.
VoIP
SIP RFC3261 protocol.
G711 coding (PCMA and PCMU), G722 and L16.
Input contacts
3 Input contacts on the control module. Configurable NC/NO. May be monitored.
16 input contacts on the UMX-C16 card (see table II). May be monitored.
The detection time of the activation pulse of the input contacts is configurable through
the Call Point software (0-50-100-200-300-400-500-1000-1500-2000 milliseconds).
Output contacts
3 Output contacts on the control module. Configurable NC/NO.
1 FAIL relay. Max. DC charge current: 150 mA. Max. DC or AC peak charge voltage: 350 V.
4 output contacts on the UMX-C16 card (see table II). Dry contacts or referenced to
ground.
Audio inputs
1 Front USB 2.0 as music input. DC output: 5V / 0.2A. Supports wav, mp3 and OGG
files.
2 Audio inputs on card UMX-EA3 (characteristics in Table III).
Internal audio channels
16
SD memory for pre-recorded messages
16 GB
Power supply
24 VDC. Dual power supply (primary and secondary).
Consumption
730 mA (without cards).
Weight
9 kg
Finishes
RAL9005 iron painted black.
Measurements
482.6 (width) x 133 (height) x 280 (depth)
Rack units
3
CARD UMX-C16. TABLE II
Position in COMPACT
Slot 1. Additional UMX-C16 cards may be inserted in slots 3 to 10.
Input contacts
16
Output contacts
4
Power supply
Through the COMPACT.
Indicators
Power indicator light.
Consumption
100 mA
CARD UMX-EA3. TABLE III
Position in COMPACT
Slot 2. Additional UMX-EA3 cards may be inserted in slots 3 to 10.
Audio inputs
2 (input A: RJ45/connector XLR; input B: RJ45)
Controls
Independent volume potentiometer for each input.
Input sensitivity
0 dBm
-20 dBm
-60 dBm
-60 dBm + speech filter
Signal/noise ratio
> 73 dB
> 73 dB
> 52 dB
> 52 dB
Frequency response
50 Hz ~17.5 kHz
50 Hz ~17.5 kHz
100 Hz ~15 kHz
300 Hz ~10 kHz
Input impedance
1.2 KΩ / 220 KΩ
Power supply
Through the COMPACT
Indicators
Power indicator light
Consumption
100 mA
