Optimus Compact - System Alarms Table: Speaker Line Errors

COMPACT version 5.0.002
28
Modular audio matrix
with IP connection
COMPACT
R +D Department
COMPONENT
GENERATING
THE ALARM
TYPE OF ALARM
DESCRIPTION
RECOVERY
C ["n":"p" ]
(n= Number of
slave, id.)
If the value is 0,
the unit is a
COMPACT)
(p= lot occupied
by the card)
NOT DETECTED
The unit "n" incorporates a card in slot
"p" that is not detected by the system,
although it does appear in the
configurations of the installation.
Check that the card is physically present
and is properly inserted
or
the card is missing. From the Call Point
software, delete the card from the
installation tree.
C ["n":"p" ]
(n= Number of
slave, id.)
If the value is 0,
the unit is a
COMPACT)
(p= Slot occupied
by the card)
CONFIGURATION
ERROR
The unit "n" incorporates a card in slot
"p" that does not appear in the
configurations of the installation.
Use the Call Point software to add the
unit to the installation tree.
or
remove the card from the COMPACT or
COMPACT-E chassis
"ZONE NAME"
LZ LINE ERROR
When monitoring the speaker line of
the indicated zone, the system detects a
low impedance error.
The impedance in the speaker line has
changed. Inspect said line and check the
status of the speakers.
If the status of the line is correct, you
can adjust the monitoring of the line
and expand the tolerance margin for
detecting the error.
"ZONE NAME"
HZ LINE ERROR
When monitoring the speaker line of
the indicated zone, the system detects a
high impedance error.
The impedance in the speaker line has
changed. Inspect said line and check the
status of the speakers.
If the status of the line is correct, you
can adjust the monitoring of the line
and expand the tolerance margin for
detecting the error.
"ZONE NAME"
AMPLIFIER
ERROR
Zone amplification error
Check the operation of the amplifier
"ZONE NAME"
SHORT LINE
ERROR
When monitoring the speaker line of
the indicated zone, the system detects a
short-circuit in the line.
Inspect that speaker line.
If the status of the line is correct, you
can adjust the monitoring of the line
and expand the tolerance margin for
detecting the error.
"ZONE NAME"
OPEN LINE
ERROR
When monitoring the speaker line of
the indicated zone, the system detects
an open line error.
Inspect that speaker line.
If the status of the line is correct, you
can adjust the monitoring of the line
and expand the tolerance margin for
detecting the error.
