Hello from Docker!
This message shows that your installation appears to be working correctly.
3.23. 26pins GPIO, I2C, UART, SPI test
3.23.1. 26 Pins description
1) Please refer to the figure below for the sequence of the 26 pins of the Orange Pi
Zero 2 development board
2) The function of the 26 pins of the Orange Pi Zero 2 development board is shown in
the table below
GPIO
No.
GPIO
Function
Pin
Pin
Function
GPIO
GPIO
No.
3.3V
1
2
5V
229
PH5
TWI3-SDA
3
4
5V
228
PH4
TWI3-SCK
5
6
GND
73
PC9
PC9
7
8
UART5_TX
PH2
226
GND
9
10
UART5_RX
PH3
227
70
PC6
PC6
11
12
PC11
PC11
75
69
PC5
PC5
13
14
GND
72
PC8
PC8
15
16
PC15
PC15
79
3.3V
17
18
PC14
PC14
78
231
PH7
SPI1_MOSI
19
20
GND
232
PH8
SPI1_MISO
21
22
PC7
PC7
71
230
PH6
SPI1_CLK
23
24
SPI1_CS
PH9
233
GND
25
26
PC10
PC10
74
3.23.2. Install wiringOP
