2) First set the GPIO port to output mode, and the third parameter needs to input
the serial number of the wPi corresponding to the pin
root@orangepi:~/wiringOP# gpio mode 2 out
3) Then set the GPIO port to output low level. After setting, you can use a multimeter
to measure the value of the pin voltage. If it is 0v, it means that the low level is set
successfully
root@orangepi:~/wiringOP# gpio write 2 0
Use gpio readall to see that the value (V) of pin 7 has become 0
4) Then set the GPIO port to output high level. After setting, you can use a multimeter
to measure the value of the pin voltage. If it is 3.3v, it means that the high level is set
successfully
root@orangepi:~/wiringOP# gpio write 2 1
Use gpio readall to see that the value (V) of pin 7 has become 1
5) The setting method of other pins is similar, just modify the serial number of wPi to
the serial number corresponding to the pin.
