Operation data
−86−
4 Parameter list
1 Operation data
The data described here can be set using any of the operation panel,
MEXE02
, or
OPX-2A
.
Up to 16 operation data can be set (operaton data No.0 to No.15).
1.1 Speed control mode
Operation data types
The following operation data is required for speed control operation.
Item Description Setting range Initial value
Operating speed
Sets the operating speed for the speed control operation. Set as the
rotation speed of the motor output shaft.
0 to 4000 r/min 0
Acceleration time
Sets the acceleration time as a time needed for the motor to reach the
rated rotation speed (3000 r/min) from the standstill state.
0.000 to 30.000 s 0.100
Deceleration time
Sets the deceleration time as a time needed for the motor to stop from the
rated rotation speed (3000 r/min).
Torque limit
Sets when limiting the motor output torque.
The peak torque can be set based on the rated torque being 100%.
0 to 250% 250
Operation data ID
When setting the operation data with the operation panel or the parameter mode of the
OPX-2A
, check the ID in the
table below.
Operation
data number
ID
Operating
speed
Acceleration
time
Deceleration
time
Torque limit
0 576 768 832 896
1 577 769 833 897
2 578 770 834 898
3 579 771 835 899
4 580 772 836 900
5 581 773 837 901
6 582 774 838 902
7 583 775 839 903
8 584 776 840 904
9 585 777 841 905
10 586 778 842 906
11 587 779 843 907
12 588 780 844 908
13 589 781 845 909
14 590 782 846 910
15 591 783 847 911
Note for inputting the value by the operation panel
Set in the following range when inputting the acceleration time or the deceleration time because the operation panel can
display 4-digit only.
Setting range
0.000 to 30.000
When setting less than one second
0.000 to 0.999
When setting one second or more
1.00 to 30.00
To Next Page
