Made in the U.S.A.
FIELD SETTINGS
If you choose to apply NH
3
or liquid fertilizer, or dry fertilizer it is advisable to consult
documented information regarding safe handling and application of NH
3
or liquid fertilizer.
Refer to recognized sources. (pg. 2 - 7)
The 1tRIPr® tail has routing holes that can be used for liquid or NH3 fertilizer tube routing.
A front and back hole on each side of the tail allows for dual tubes to be held in place.
NOTE: If applying two different types of fertilizer, like NH3 through one tube and liquid
fertilizer through the other tube it is the responsibility of the user to adequately insulate, or
add additional space between the tubes in order that the NH3 does not freeze the liquid
Fertilizer Tube
Example
Fertilizer Tube Routing Holes
(each side)
D A N G E R
5 - 14
To Next Page
