Made in the U.S.A.
PARTS IDENTIFICATION
ROW UNIT ASSEMBLY
(diagram on previous page)
Key Part # Description Qty. Notes
1 387-070 Mount & Parallel Linkage Assembly 1 see breakdown on page 7 - 3
2 385-943 Depth Band Coulter & Hub Assembly 1 see breakdown on page 7 - 4
3 387-051 Row Cleaner Assembly 1 see breakdown on page 7 - 5
4 385-498 Wavy Coulter and Shank Right Assembly 1 see breakdown on page 7 - 8
5 385-498 Wavy Coulter and Shank Left Assembly 1 see breakdown on page 7 - 8
6 387-050 Mole Shank Assembly 1 see breakdown on page 7 - 6
7 385-854 Scraper Assembly 1 Includes items #8 thru #12
8 100-003 Carriage bolt 2 5/16” x 1”, Grade 5
9 108-006 Flat washer 2 5/16”
10 108-017 Lock washer 2 5/16”
12 102-004 Nut 2 5/16”
13 100-274 Bolt 1 3/4” x 9 1/2”, Grade 8
14 387-150 Main Frame 1 Includes #15 thru 18
15 134-067 Bushing 4 1 1/4” OD x 1” ID x 2 1/2” long
16 110-001 Grease Zerk 2 1/4” Straight
17 134-017 Bushing 1 1 3/4 OD x 1 1/2 ID x 1” long
18 134-034 Bushing 1 1 1/4” OD x 1” ID x 1” long
19 104-094 Hair Pin 1 5/32” x 3 1/4”
20 313-469 Pin 1
21 100-160 Bolt 1 3/4” x 3”, Grade 5
22 102-121 Flanged nut 2 3/4” x 3”, Grade 5
23 100-122 Bolt 1 1/2” x 3”, Grade 5
24 108-020 Lock washer 1 1/2”
25 102-007 Nut 1 1/2”
26 106-160 Set screw 2 5/8” x 2 1/2”, Square head
27 102-016 Jam nut
6 5/18”
28 106-149 Set screw 4 5/8” x 1 1/2”, Square head
29 100-031 Carriage bolt 4 5/8” x 1 3/4”, Grade 5
30 387-115 Cross Tube 2
31 313-293 Cap 2
32 102-108 Flanged nut 2 3/4”
33 102-029 Lock nut 2 5/8”
7 - 2
