Owon DGE3000 Series User Manual

5.Panel Operation
10
Set the amplitude
Press the Amplitude/High Level softkey to confirm whether the Amplitude
menu item is highlighted; if not, press the Amplitude/High Level sofkey to
switch to Amplitude. In Parameter 2 of Figure 5-2, a blinking cursor appears
in the parameter value of amplitude. Turn the knob to change the value directly,
or use the numeric keypad to input the desired value and choose the unit.
Set the offset
Press the Offset/Low Level softkey to confirm whether the Offset menu item
is highlighted; if not, press the Offset/Low Level softkey to switch to Offset. In
Parameter 3 of Figure 5-2, a blinking cursor appears in the parameter value of
offset. Turn the knob to change the value directly, or use the numeric keypad
to input the desired value and choose the unit.
Set the high level
Press the Amplitude/High Level softkey to confirm whether the High Level
menu item is highlighted; if not, press the Amplitude/High Level softkey to
switch to High Level. In Parameter 2 of Figure 5-2, a blinking cursor appears
in the parameter value of high level. Turn the knob to change the value directly,
or use the numeric keypad to input the desired value and choose the unit.
Set the low level
Press the Offset/Low Level softkey to confirm whether the Low Level menu
item is highlighted; if not, press the Offset/Low Level softkey to switch to Low
Level. In Parameter 3 of Figure 5-2, a blinking cursor appears in the
parameter value of low level. Turn the knob to change the value directly, or
use the numeric keypad to input the desired value and choose the unit.
Set the Phase
Press the Phase softkey, the Phase menu item is highlighted. In Parameter 4
of Figure 5-2, a blinking cursor appears in the parameter value of Phase. Turn
the knob to change the value directly, or use the numeric keypad to input the
desired value and choose the unit.
Output Square Wave
Press , the screen displays the user interface of the square wave. The
Square waveform parameters can be set by operating the Square setting
menu on the right.
The square wave menu includes: Frequency/Period, Amplitude/High Level,
